Wall Mount AP-Products-Shenzhen Yunlink Technology Co., Ltd.©2023







Model	FAP812
CPU	MT7621DAT+MT7615DN
Flash	SPI NOR 8MB
DDR3L	128M
2.4G Frequency	2.4GHz ~ 2.484GHz
2.4G Protocol	802.11 b / g / n
5G Frequency	5.150GHz～5.850GHz
5G Protocol	802.11 a / n / ac
2.4G Antenna	2*2dBi
5G Antenna	2*2dBi
Data Rate	5G: 867Mbps 2.4G:300Mbps
2.4G TX Power	802.11b	11M	17±2dBm	1M	18±2dBm
	802.11g	54M	16±2dBm	6M	17±2dBm
	802.11n HT20	MCS7	16±2dBm	MCS0	17±2dBm
	802.11n HT40	MCS7	15±2dBm	MCS0	16±2dBm
5G TX Power	802.11a	54M	16±2dBm	6M	17±2dBm
	802.11n HT20	MCS7	15±2dBm	MCS0	16±2dBm
	802.11n HT40	MCS7	15±2dBm	MCS0	16±2dBm
	802.11ac HT80	MCS9	14±2dBm	MCS0	15±2dBm
2.4G Receiving Sensitivity	802.11b	11M	-84dBm	1M	-88dBm
	802.11g	54M	-72dBm	6M	-86dBm
	802.11n HT20	MCS7	-70dBm	MCS0	-84dBm
	802.11n HT40	MCS7	-68dBm	MCS0	-82dBm
5G Receiving Sensitivity	802.11a 802.11n HT20 802.11n HT40 802.11ac HT80	54M	-70dBm	6M	-86dBm
		MCS7	-68dBm	MCS0	-84dBm
		MCS7	-66dBm	MCS0	-82dBm
		MCS9	-56dBm	MCS0	-80dBm
2.4G EVM	802.11b: ≤-10 dB；802.11g: ≤-25 dB；802.11n: ≤-28dB
5G EVM	802.11a: ≤-25 dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB
ppm	±20ppm
WAN	1*10/100/1000M WAN, support 48V POE
LAN	1*10/100/1000M LAN
POE	802.3af
Reset	Reset to factory settings by pressing 6-10 seconds
Indicators	SYS
Max Power Consumption	<12W
ESD	Air:±8K, Touch:±6K
Electrical Surge	Common Mode: 1K, Differential Mode: 0.5K
Size	86mm86mm42.8mm
Weight	0.15kg
Temperature	Working: -10°C to 40°C；Storage: -40°C to 70°C；Humidity: 5％～95％(Non-Condensing)
