Product model

DR-980GP

CPU

MT7621AT

FLASH

16MB

DDR3

512MB

Port

1*10 / 100 / 1000M adaptive WAN port

1*10 / 100 / 1000 MLAN / WAN port

8*10 / 100 / 1000M adaptive LAN ports with 48V POE output

PoE

Power supply output supports IEEE 802.3af(15.4W), IEEE 802.3at (30W)

Reset Button

Reset butotn (long press for 6-10 seconds to restore the default factory configuration)

Status indicator light

PWR lamp: always on; SYS lamp: flashing during operation;

PoE lamp 8; the yellow light is always on when connecting the PoE equipment;

Link lamp 10; Link / Act LED: green light during connection and flashing during network communication;

DC input

DC 54V/1.4A

Max power consumption

＜10W

Size

190mm*97.5mm*29.5mm

Weight

0.46kg

Electrostatic protection grade

Air discharge ± 8KV, contact discharge ± 6KV

Wave surge level

Common mode ± 2KV and difference mode ± 1KV

Work environment

Operating temperature: -20℃ ~ + 55℃;

Storage temperature: -40℃ ~ + 70℃;

Humidity: 5%~95% (no condensation)

AP manage

The maximum number of managed users is 128 users

The AP management number is 128 units

Centralized and remote management, to configure the wireless AP

Equipment overview

Total number of users, current links, online devices, and offline devices

On-access real-time rate, running time, user management, device management

Equipment information, equipment description, Intranet information, extranet information

device management

List of equipment

Template Settings

Device upgrade

service configuration

IPTV set up

Automatic roaming

user management

User list

User speed limit

Security center

IP filter

MAC filter

Website filtering

port mapped

DMZ set up

Network function

Connection mode: static address, dynamic acquisition (DHCP), broadband dial (PPPOE), bypass mode

DHCP server: either built-in DHCP server or external DHCP server

Cloud platform server

system management

Backup Configuration Information

Restore configuration information

factory data reset

Restart immediately

firmware upgrade

Time management includes the system display time and time synchronization

system log
