HARDWARE FEATURES |
Chipset | MT7628DAN+MT7613BEN |
Flash | 8M Flash |
DDR | 64M DDR |
Interface | 1*10/100Mbps WAN port 1*10/100Mbps LAN ports 1*WiFi Switch On/Off button 1*Reset button |
Power Supply | 48V PoE, IEEE 802.3af standard |
Maxi power consumption | < 6W |
Dimensions (W X D X H) | 87*86*35.8mm |
Antenna Type | On board WiFi antenna 2.4G: 3dBi omni antenna |
WIRELESS FEATURES |
Wireless Standards | IEEE 802.11n/g/b 2.4GHz |
Frequency | 2.4GHz – 2.484GHz |
Signal Rate | Up to 300Mbps |
RF Power (2.4GHz) | 802.11b | 11M | 17±2dBm | 1M | 19±2dBm |
802.11g | 54M | 16±2dBm | 6M | 18±2dBm |
802.11n HT20 | MCS7 | 15±2dBm | MCS0 | 17±2dBm |
802.11n HT40 | MCS7 | 14±2dBm | MCS0 | 16±2dBm |
Receive Sensitivity (2.4GHz) | 802.11b | 11M | -82dBm | 1M | -94dBm |
802.11g | 54M | -72dBm | 6M | -90dBm |
802.11n HT20 | MCS7 | -70dBm | MCS0 | -88dBm |
802.11n HT40 | MCS7 | -68dBm | MCS0 | -86dBm |
Wireless | Auto-Channel selection |
Distance Control (802.1x Ack timeout) |
Multiple SSID up to 4 |
BSSID |
EVM | 2.4G: 802.11b: ≤-10 dB; 802.11g: ≤-25dB; 802.11n: ≤-28 dB |
PPM | ±20ppm |
Max Access Users | 64 |
Operation Mode | Wireless AP, Gateway, Wi-Fi Repeater |
Wireless Security | 64/128-bit WPA / WPA2, WPA-PSK/ WPA2-PSK encryption and RADIUS 802.1x |
ESD - I | Air discharge:±4KV |
Surge-I | Common-mode±2KV |
LED Status | SYS |
Management |
System Settings | Web-based configuration / Software AC controller and Hardware AC controller management |
Firmware Upgrade | Upgrade firmware via web browser or AC controller |
Administration | Admin Password can be configured |
System monitoring | Watch dog, Status in hand , useful statistic and Event log |
Logs | Supports local logs, logs host, logs file export |
Reset | Reset or factory defaults |
Backup | Restore settings & configuration of the device to local file, Scheduled reboot |
OTHERS |
|
Package Contents | 300Mbps wireless access point Quick Installation Guide Setting Accessory |
|
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows 8, Windows 10, MAC OS, NetWare, UNIX or Linux |
|
Environment | Operating Temperature: -20~55 ℃ Extreme Temperature: -40~70 ℃ Storage Temperature: -40~70 ℃
Humidity: 5%~95% non-condensing |
|
