Specification parameters
Product model	AP 1200F
CPU	MT7628DAN+ MT7613BEN
Flash	8MB
DDR2	Built-in, 64MB
2.4G frequency	2.4GHz – 2.484GHz
2.4G WIFI Standard	802.11 b / g / n
5G frequency	5.150GHz～5.850GHz
5G WIFI Standard	802.11 a/ n / ac
External dual-frequency antenna	22.4GHz / 5GHz omnidirectional dual-frequency antennas, each gain: 5 dBi
top speed	2.4G provides a maximum access rate of 300Mbps, and 5G to 866Mbps
2.4G wireless power	802.11b	11M	19±2dBm	1M	20±2dBm
	802.11g	54M	17±2dBm	6M	19±2dBm
	802.11n HT20	MCS7	16±2dBm	MCS0	18±2dBm
	802.11n HT40	MCS7	16±2dBm	MCS0	18±2dBm
5G wireless power	802.11a	54M	17±2dBm	6M	19±2dBm
	802.11n HT20	MCS7	16±2dBm	MCS0	18±2dBm
	802.11n HT40	MCS7	16±2dBm	MCS0	18±2dBm
	802.11ac HT80	MCS9	15±2dBm	MCS0	17±2dBm
2.4G sensitivity	802.11b	11M	-85dBm	1M	-94dBm
	802.11g	54M	-73dBm	6M	-90dBm
	802.11n HT20	MCS7	-71dBm	MCS0	-89dBm
	802.11n HT40	MCS7	-68dBm	MCS0	-86dBm
5G sensitivity	802.11a	54M	-73dBm	6M	-90dBm
	802.11n HT20	MCS7	-71dBm	MCS0	-89dBm
	802.11n HT40	MCS7	-68dBm	MCS0 .	-86dBm
	802.11ac HT80	MCS9	-56dBm	MCS0 .	-81dBm
2.4G EVM	802.11b：≤-10 dB ；802.11g: ≤-25 dB ；802.11n: ≤-28 dB
5G EVM	802.11a: ≤-25dB ；802.11n: ≤-28 dB ；802.11ac: ≤-32 dB
frequency deviation (ppm)	±20ppm
joggle (WAN)	110 / 100M adaptive WAN port, supporting 24 VPOE
joggle (LAN)	110 / 100M adaptive LAN port
key	Set key (press 6-10 seconds to restore factory default configuration)
Status indicator light	PWR lamp, WAN port lamp, LAN port lamp, 2.4G lamp, 5.8G lamp
supply electricity	24V Passive PoE ，12V /1A DC
maximum power dissipation	< 7W
Product feet	196mm86mm40mm
weight	0.4kg
work environment	Normal operating temperature: -30°C to 55°C; storage temperature: -40°C to 70°C; humidity: 5%~95% (no condensation)
levels of protection	IP65
ESD	Air discharge + / -8K, contact discharge + / -6K
surge	Co-mode 4K and difference mode 2K

Home page	Working mode:, fat AP mode and thin AP mode
	Wireless AP download rate, wireless AP upload rate, and runtime
	Equipment information, equipment description, Intranet information, and WIFI information
Support mode	Gateway mode: the device is connected to the WAN network through the WAN port and connected to the Internet using static IP, DHCP or PPPOE
	Relay mode: In this mode, the device overrides wireless network signals to other clients or devices and connects to other routers using the WAN
	AP mode: Devices cover wireless network signals over other clients and devices, and use Ethernet to connect to other routers for WAN access
Wireless function	SSID broadcasting
	SSID quantity: 4(2.4GHz) + 4 (5GHz), supporting Chinese SSID
	Hide the SSID functionality
	Wireless encryption: OPEN, WPA / WPA2PSK-TKIPAES, WPA3PSK-TKIPAES
	Wireless MAC address filtering: support whitelist
	Spectrum navigation (5G is preferred)
	WiFi is turned off
	User isolation: isolation between wireless networks and AP internal isolation
	Emission power setting
	Limited number of wireless clients
	QoS：WMM
Network function	Connection mode: static address, obtained from the management server, obtained from the gateway
	DHCP server: either built-in DHCP server or external DHCP server
	Cloud platform server
	Firewall function
	PPPOE function: support PPPOE dialing function
Management	Backup Configuration Information
	Restore configuration information
	factory data reset
	The boot includes timing restart and immediate restart
	firmware upgrade
	Time management includes the system display time and time synchronization
	system log
	Fat and thin AP switching function
