4G Module information
LTE Module Model			Quectel EC25-AU, LTE-CAT4 as example (Also support other module) Quectel EC20 R2.1 (China, India) B1/B3/B5/B7/B8/B20@FDD LTE, B1/B5/B8@WCDMA; B2/B3/B5/B8@GSM Quectel EC25 R2.1 (China, India) B2/B4/B12@FDD LTE; B2/B4/B5@WCDMA; or B2/B4/B5/B12/B13/B14/B66/B71@LTE FDD,B2/B4/B5@WCDMA
Band Support			GSM: B2/3/5/8; WCDMA: B1/2/5/8; LTE FDD: B1/2/3/4/5/7/8/28; LTE TDD: B40
LTE Data Rate			LTE-FDD: max 150(DL)/Max 50(UL) ，LTE-TDD: max 130(DL)/Max 35(UL)
Name			Details
CPU			MT7628+MT7613AE
FLASH			8MB
SDRAM			64MB
DC-DC			12V 1A
Name			Content
Working Temperature			-30℃ ～ +55℃
Max Working Temperature			-40℃ ～ +85℃ (Throughput some decrease)
Storage Temperature			-40℃ ～ +70℃
Humidity			5％～95％ (No Condensation)
Name			Content
Wi-Fi			Support Auto Channal, Guest SSID, SSID hide, Wireless MAC filter, white and black list
Net			PPPoE, Automatic IP, Static IP, L2TP, PPTP, 4G
			Support automatically switch between WAN/ISP and 4G
			Support VPN server and VPN client: PPTP, L2TP and OpenVPN
			Support AP+Client
Firewall			Support NAT, URL Filter, MAC Filter and Network Service Filter
			Support DoS attack protection, SYN flood attack
			WAN PING,SSH, HTTP Access
Other functions			NTP and account setup; Port forwarding，Virtual Server，Watchdog，DMZ，DDNS
2.4G RF Power	802.11b	11M		17±2dBm	1M	19±2dBm
	802.11g	54M		16±2dBm	6M	18±2dBm
	802.11n HT20	MCS7		15±2dBm	MCS0	17±2dBm
	802.11n HT40	MCS7		15±2dBm	MCS0	17±2dBm
5.8G RF Power	802.11a	54M		17±2dBm	6M	19±2dBm
	802.11n HT20	MCS7		16±2dBm	MCS0	18±2dBm
	802.11n HT40	MCS7		15±2dBm	MCS0	17±2dBm
	802.11AC	MCS9		14±2dBm	MCS0	16±2dBm
2.4G Receive Sensitivity	802.11b	11M		-85dBm	1M	-94dBm
	802.11g	54M		-72dBm	6M	-90dBm
	802.11n HT20	MCS7		-70dBm	MCS0	-88dBm
	802.11n HT40	MCS7		-68dBm	MCS0	-86dBm
5.8G Receive Sensitivity	802.11a	54M		-68dBm	6M	-86dBm
	802.11n HT20	MCS7		-68dBm	MCS0	-86dBm
	802.11n HT40	MCS7		-65dBm	MCS0	-83dBm
	802.11AC	MCS9		-55dBm	MCS0	-73dBm
2.4G EVM	802.11b: ≤-10dB; 802.11g: ≤-25 dB; 802.11n: ≤-28 dB
5.8G EVM	802.11a_54M: ≤-25 dB; 802.11n_MCS7: ≤-28 dB; 802.11AC_MCS9:≤-32dB
PPM	±20ppm
Channel	1～13, Support auto channel
Standard	802.11b/g/n
Bandwidth	HT20, HT40, HT80, HT20/HT40/HT80
Security	Open System, Shared key, WPA-Personal, WPA2-Personal, WPA-Auto-Personal, WPA-Enterprise(Radius), WPA2-Enterprise(Radius), WPA-Auto-Enterprise(Radius), Radius with 802.1x
RF Power Adjustable	Support
