Chipset

IPQ6010+5022+5052+QCA8081+QCA8075

Standard

802.11ax/ac/b/g/n

DDR

512MB(16bit)*2=1GB, maxi up to 2GB

Flash

NOR-8MB AND NAND-128MB

2.4G Frequency

2.4GHz - 2.484GHz

2.4G Wi-Fi standard

802.11b/g/n

5.8G Frequency

5150~5850MHz

5.8G Wi-Fi Standard

802.11 ax/ac

Interface

1 * 10/100 /1000/2500Mbps RJ45 WAN Port (WAN port support 24~48V passive in if need, but if WAN port support PoE in, LAN ports can’t support PoE out)

4 * 10/100 / 1000Mbps RJ45 LAN Ports(Support 48V active PoE out if powered by DC)

1 * Reset

1 * SIM card slot support 4G/5G, M.2 interface

1 * USB3.0 Port

1 * SD Card Slot

1 * Type C USB

1 * Circular DC Connector, support 12~48V

Mark:

If with 12V DC power adapter, WAN/LAN ports no PoE function;

If with 48V/3A DC power adapter, LAN ports support 48V active PoE out, WAN port no PoE function.

If with 24V PoE adapter, WAN port support 24V  Passive PoE in, LAN ports no PoE function

For home use model, it with 12V/1.5A DC power adapter

Antenna

SMA Connector, for home use

4*5dBi omni WiFi antennas

4*4G/5G antenna

Data Rate

1800Mbps  (2.4G: 591Mbps (11ax 2x2); 5.8G: 1238Mbps (11ax 2x2)）

End Users

150+

RF Power

2.4g ≤ 24dBm

5.8g ≤ 24dBm

DC

12V~48V

LED light

Sys; 5.8G wifi;  2.4G wifi;  WAN; LAN, 5G; 4G, GPS

Max Power Consumption

≤ 60W

Size

TBD

Weight

TBD

Working Temperature

-20°C to 45°C

Storage Temperature

0°C to 70°C

Humidity

5％～95％ (non-condensing)
