CPU

QCA9563+QCA9882+QCA8334

Flash

SPI NOR 16MB

DDR2

64MB

5G Band

5.150GHz～5.850GHz

5G WIFI Protocol

802.11 a / n /ac

Maximum rate

900Mbps

Antenna

Integrated 25dBi dual polarization dish antenna

5G Tx power

802.11a

54M

23±2dBm

6M

26±2dBm

802.11n HT20

MCS7

22±2dBm

MCS0

26±2dBm

802.11n HT40

MCS7

22±2dBm

MCS0

26±2dBm

802.11ac VHT20

MCS9

21±2dBm

MCS0

26±2dBm

5G Receiving sensitivity

802.11ac VHT40

MCS9

21±2dBm

MCS0

26±2dBm

802.11ac VHT80

MCS9

21±2dBm

MCS0

26±2dBm

802.11a

54M

-75dBm

6M

-92dBm

802.11n HT20

MCS7

-72dBm

MCS0

-90dBm

5G EVM

802.11a_54M: ≤-25 dB；802.11n_MCS7: ≤-28 dB；802.11AC_MCS9:≤-32dB

frequency deviation（ppm）

±20ppm

Port (WAN)

1*10/100/1000M WAN, support 48V POE

Port（LAN）

1*10/100/1000M LAN

Supply

802.3af，DC 12~24V

Consumption

<10W

Reset Button

Long press for 6-10 seconds to restore factory default configuration

LED

SYS, WAN, LAN, 5G WIFI, signal*4

Size

Φ466mm*260mm

Weight

2.9KG

Environment

Operating temperature: -40°C to 70°C

Storage temperature: -40°C to 70°C；humidity：5％～95％（No condensation）

IP grade

IP65

ESD

Air +/-8K，Contact +/-6K

Surge protection

Common-Mode: 4K，Differential-Mode: 2K
